Branchus Creations | Building a Baby Macintosh Quadra 700 @BranchusCreations | Uploaded June 2024 | Updated October 2024, 11 hours ago.
Have you ever heard of a Quadra 233? Learn how to build your own baby Macintosh Quadra 700 using a Raspberry Pi and a 3D printed case. With your pocket-sized* Quadra 700 you'll be the envy of all other Quadra 700 owners out there.
*Large pocket required.
CHAPTERS
00:20 Quadra 700
01:21 Modelling the Quadra 700
02:32 OnShape
04:26 Raspberry Pi 4
05:29 OnShape public models
05:57 First print
06:22 My first mini Mac build
06:53 Adding cooling and speakers
08:40 Setting up the Raspberry Pi
09:36 Installing RetroPie
10:53 Configure gamepad (keyboard)
11:48 Configure WiFi
13:36 Install Basilisk
14:44 Disk image & ROM
16:56 Booting the Mac for the first time
17:27 Fixing display underscan
18:25 Configuring Basilisk
20:27 Adjusting the resolution
21:49 Unix drive file transfer
22:48 Output sound to the headphone jack
23:47 Printing the case in beige
