Only $5 for 10 PCBs and every new member get $5 bonus. + Express 24 hour / 48 hour service on pcbway.com ➠ ➠ ➠ In this video, I showcase my custom-designed 50Ω digitally controlled stepped attenuator, perfect for RF radio work. With 3dB steps up to 93dB of attenuation, this precision tool uses a combination of pi attenuator resistors, relays, an Arduino Nano, a rotary encoder, and a vibrant OLED display. It also features an integrated IEC dummy antenna circuit, ideal for simulating antenna signals during RF alignments.
Key features include:
• Stepped Attenuation: Achieve precise attenuation from 0dB to 93dB in 3dB steps.
• User-Friendly Controls: Simple rotary encoder interface with an OLED display for real-time feedback.
• 50Ω Impedance Matching: Ensures accurate RF performance.
• Dummy Antenna Circuit: Switchable for RF alignment tasks.
I’ve provided everything you need to build your own, including:
✅ Gerber files
✅ Schematic
✅ Bill of Materials (BOM)
✅ 3D print files for a custom enclosure
✅ Arduino Sketch Code
Want to build it? Order the two PCBs directly from PCBWay using the links below. Plus, I’ll be offering pre-programmed Arduino Nano modules at cost for those interested.
🎥 Watch now and bring this project to life!
🔗 Google Drive Folder: drive.google.com/drive/folders/1PV1SY4eCkOfOLt00cmZrMohOg8gdraSR?usp=sharing
🔗PCBWay Shared Relay Board: pcbway.com/project/shareproject/Digital_Switched_Attenuator_Relay_Board_f4e2e8ce.html
🔗PCBWay Shared Control Board: pcbway.com/project/shareproject/Digital_Switched_Attenuator_Control_Board_4181cead.html
🎥 Other videos mentioned in this video:
■ Arduino Meets Tube Radios: Building a Switched Pi Attenuator (0-93dB) For Alignments - youtu.be/71RxyF2FU_s
■ Switchable Pi Attenuator with Dummy Antenna - youtu.be/3omksRXF7Sc
Like, share, and subscribe for more RF and electronics projects!
