The diode clipper, also known as a diode limiter, is a wave shaping circuit that limits positive or negative amplitude, or both. In electronics, diode clipper circuits are commonly used to process various signals. It is is a circuit designed to prevent a signal from exceeding a predetermined reference voltage level. Clipping changes the shape of the waveform and alters its spectral components.
