Updated my first racer to Betaflight 2.8.1, Multishot 14.6. Gyro and PID process running at 4kHz, motor pwm rate at 16kHz. Rate settings see below.

Great smooth feeling, no yaw jumps anymore. If this is the "KISS-feeling" then it's a good feeling. Have to fiddle a bit with the rate setting, but not to bad for the first go. Gonna update the other ones now ...

Only problem I had was my buddies ET200 VTX, which changed frequency by itself ;-)

Full Setup:
LSX233 High Version (sorry, you can not buy this one anywhere, maybe in the future ...)
SP Racing F3 (banggood.com/Upgrade-NAZE32-SP-Racing-F3-Flight-Control-6-DOF-10-DOF-for-Milticopter-p-1010232.html?p=MI02017998062014105Q)
Matek PDB Power Hub V2.1 (banggood.com/Matek-Mini-Power-Hub-Power-Distribution-Board-With-BEC-5V-And-12V-For-FPV-Multicopter-p-1005549.html?p=MI02017998062014105Q)
Hobbywing XRotor 20A ESC BLHeli latest (banggood.com/Hobbywing-XRotor-20A-APAC-Brushless-ESC-3-4S-For-RC-Multicopters-p-945929.html?p=MI02017998062014105Q)
Emax RS2205 2300kv Motors (banggood.com/4X-Emax-RS2205-2300-Racing-Edition-CWCCW-Motor-For-FPV-Multicopter-p-1032857.html?p=MI02017998062014105Q)
DAL T5045 V2 Props (surveilzone.com/2-Pairs-Tri-blade-DALprop-T5045-Bullnose-Props-for-FPV-Racing-g-1490)
Runcam Sky+ PZ0420M FPV-Cam (banggood.com/RunCam-Magnesium-Alloy-Housing-SkyPlusPZ0420M-600TVL-18g-Wide-Voltage-PALNTSC-Mini-FPV-Camera-For-QAV250-p-1000577.html?p=MI02017998062014105Q)
Eachine ET200R 40Ch VTX (banggood.com/Eachine-ET200R-FPV-5_8G-40CH-200mW-Mini-AV-Transmitter-with-RaceBand-p-1022303.html?p=MI02017998062014105Q)
Aomway CL Antenna (banggood.com/Aomway-5_8GHz-FPV-4-Leaf-Clover-AV-Transmission-RHCP-Antenna-1-Pair-p-961730.html?p=MI02017998062014105Q)
FrSky X4R-SB (s.bus, Smartport Telemetrie) (banggood.com/FrSky-X4RSB-316-Channel-Telemetry-Receiver-p-955643.html?p=MI02017998062014105Q)
Runcam 2 HD Cam (banggood.com/RunCam-2-RunCam2-HD-1080P-120-Degree-Wide-Angle-WiFi-FPV-Camera-p-1017010.html?p=MI02017998062014105Q)
Some LED (banggood.com/Diatone-3-4S-LED-Decoration-Board-Strip-Set-For-250-Class-Frame-p-961260.html?p=MI02017998062014105Q)
Custom 3D printed Parts

Multishot 14.6 Files are found here: rcgroups.com/forums/showpost.php?p=34843343&postcount=2224

Here are the settings:
set gyro_sync_denom = 2
set pid_process_denom = 1
set unsynced_fast_pwm = ON
set fast_pwm_protocol = MULTISHOT
set motor_pwm_rate = 16000

set pid_controller = MWREWRITE
set p_pitch = 65
set i_pitch = 48
set d_pitch = 25
set p_roll = 42
set i_roll = 40
set d_roll = 19
set p_yaw = 90
set i_yaw = 45
set d_yaw = 0
set p_alt = 50
set i_alt = 0
set d_alt = 0
set p_level = 50
set i_level = 50
set d_level = 100
set p_vel = 55
set i_vel = 55
set d_vel = 75
rateprofile 0

# rateprofile
rateprofile 0

set rc_rate = 120
set rc_rate_yaw = 120
set rc_expo = 20
set rc_yaw_expo = 0
set thr_mid = 50
set thr_expo = 0
set roll_rate = 78
set pitch_rate = 78
set yaw_rate = 78
set tpa_rate = 20
set tpa_breakpoint = 1500

Enjoy :-)
