Software updates and answers to some frequently asked questions about the new Amiga RGBtoHDMI adapter using a Raspberry Pi Zero.
My original Amiga RGBtoHDMI video: youtu.be/e8brkYFoO9I
c0pperdragon's RGBtoHDMI Amiga adapter GitHub: github.com/c0pperdragon/Amiga-Digital-Video
The RGBtoHDMI project: github.com/hoglet67/RGBtoHDMI/wiki
My Twitch stream using the RGBtoHDMI and my Amiga 500: twitch.tv/videos/866228710
Jan Beta's Playground on YouTube (my archived streams): youtube.com/user/jantanplan
Buy a Raspberry Pi Zero (affiliate links)*:
US: amzn.to/2Lr9bLr
UK: amzn.to/38fSz21
DE: amzn.to/3op3HPO
c0pperdragon Denise Adapter Board BOM (derived from Kicad files):
U1: 74LVC86 / Package: TSSOP-14 (4.4x5mm P0.65mm)
U2, U3: 74LVC574 / Package: TSSOP-20 (4.4x6.5mm P0.65mm)
U4: TLV74333PDBVR / Package: SOT-23-5
C1, C2, C3: 100nF SMD 0603 Ceramic Capacitor
C4: 1uF SMD 0805 Ceramic Capacitor
R1: 3k3 Ohms SMD 0805 Resistor
2x Pin Header 1x24 Pins 2.54mm vertical
2x DIP-24 W15.24mm Socket (or 1 DIP-48 Socket)
PinSocket 2.54mm 2x20 vertical (Raspi)
PinHeader 2.54mm 1x02 horizontal (for Button)
PinHeader 2.54mm 1x03 horizontal (Denise select)
