Aerogel has been around for over 80 years. It was developed by Dr. Samuel Kistler in the 1930’s at the College of Pacific in California. Only recently has it been improved and integrated into many processes today. It is an extremely porous (up to 99%) and lightweight solid derived from a gel of silica or other materials (carbon nanotubes, giant graphene oxide sheets, etc.). The process of transforming the gel into a solid is to replace the liquid component of the gel with a gas. The resulting solid has a very low density, close to that of air, and can exhibit different properties based on the process by which it is created. These various properties allow aerogel to be incredibly useful for various systems. Aerogel’s main use today is as a thermal insulator. However, with continued research and investment, it can serve an entirely different purpose: oil absorption. The normally hydrophilic aerogels can be manipulated through a process called functionalization to become hydrophobic and thus oil absorbent. The continued development of this property of some aerogels can improve the process by which oil spills are cleaned up. This material has the potential to replace many of the sorbents that are used today to clean up oil spills.
Group Members:
Casey Martin
Daniel Shapiro
Kean Finucane
Matthew Hill
Aerogel has been around for over 80 years. It was developed by Dr. Samuel Kistler in the 1930’s at the College of Pacific in California. Only recently has it been improved and integrated into many processes today. It is an extremely porous (up to 99%) and lightweight solid derived from a gel of silica or other materials (carbon nanotubes, giant graphene oxide sheets, etc.). The process of transforming the gel into a solid is to replace the liquid component of the gel with a gas. The resulting solid has a very low density, close to that of air, and can exhibit different properties based on the process by which it is created. These various properties allow aerogel to be incredibly useful for various systems. Aerogel’s main use today is as a thermal insulator. However, with continued research and investment, it can serve an entirely different purpose: oil absorption. The normally hydrophilic aerogels can be manipulated through a process called functionalization to become hydrophobic and thus oil absorbent. The continued development of this property of some aerogels can improve the process by which oil spills are cleaned up. This material has the potential to replace many of the sorbents that are used today to clean up oil spills.
Group Members:
Casey Martin
Daniel Shapiro
Kean Finucane
Matthew Hill






![Xenon MCV - Aerogel as a Thermal Insulator
Aerogel as a Thermal Insulator
Brooke Adams
Hyoeun Kim
Oscar Sandoval
Scott Weiss
Our chosen technical challenge is the loss of energy due to poor insulators in building infrastructure. The problem with the insulators of todays buildings is that they are composed of materials that are not energy efficient in the long run. For starters, a typically large amount of material is needed for the insulators to even accomplish their task, compromising space in the building that is not necessary for its construction. Todays insulators also tend to be brittle, calling out for maintenance fees that make the tenure of the material to be expensive as well. Should a thermal insulator be inefficient in its duty, the more energy is needed for a building to stay warm or cold during the extreme seasonal temperatures occurring throughout the year. Energy unnecessarily spent compromises the source of where it is obtained from, depleting the already stretched energy sources demanded by humans worldwide.
Our chosen material will address many of these dilemmas in a unique and efficient way. Our chosen solution for the problem of insulation is the use of a green material named Aerogel. Aerogel is amazing for addressing thermal insulation because its composition almost nullifies almost all methods of heat transfer (convection, conduction, and radiation). This is due to the fact that the material is composed of 99.98% air, which is a terrible thermal conductor due to its properties as a gas. Aerogel also has other incredible properties such as being 500 times the strength of its counterpart silica aerogel. This could be because aerogel has certain polymers that support the silica chains within it, such as polyimide, along with interchain linking (networking). Aerogels are also extremely thin, hydrophobic, breathable, and fireproof, adding more properties that make it a desirable thermal insulator. The processing of aerogels is very costly, however, leading to expensive pricing for its acquisition. Although its cost may be exorbitant, aerogels astounding properties grants it much potential as a green building material in thermal insulation.
Works Cited:
[ RT ISOLAZIONI - Soluzioni termoisolanti in Aerogel ] - Tecnologia Aerogel. (n.d.). Retrieved April 27, 2014, from http://www.rtisolazioni.com/technology.php
Berge, A., & Johansson, P. (2012). Literature Review of High Performance Thermal Insulation (2). Retrieved from Chalmers University of Technology website: http://publications.lib.chalmers.se/records/fulltext/local_159807.pdf
Fricke, J., & Tillotson, T. (1997). Aerogels: production, characterization, and applications. Thin Solid Films, 297(1-2), 212-223. doi:10.1016/S0040-6090(96)09441-2
The Frontier - Aerogels: Their History, Structure, and Applications. (n.d.). Retrieved April 27, 2014, from http://geobeck.tripod.com/frontier/aerogels.html#link
Gromicko, N. (n.d.). Aerogel - Intl Association of Certified Home Inspectors (InterNACHI). Retrieved April 27, 2014, from http://www.nachi.org/aerogel.htm
Hartmann, J., Rubin, M., & Arasteh, D. (1987). Thermal and Solar-optical Properties of Silica Aerogel for Use in Insulated Windows. Retrieved from U.S. Department of Energy website: http://eande.lbl.gov/sites/all/files/publications/23386.pdf
What Makes Polymers Different? (n.d.). Retrieved April 27, 2014, from http://pslc.ws/macrog/kidsmac/differnt.htm
