Video Description
This video discusses the use of your FT-991A’s DATA Upper Side Band mode, as opposed to the normal USB mode, for digital modes, and – in particular, because they are close cousins mode-wise - the JS8Call and FT-8 communications.
Having two DSP settings – one for data and another for voice, makes swapping from one to the other as easy as selecting the appropriate mode.
Links:
RT-Systems: rtsystemsinc.com/FT-991A_c_807.html
Diamond D-30A Dummy Load: geni.us/bxB7PZ
FT-991A Menu Settings
031 CAT RATE: 9600
(You can use any value – note the CAT RATE)
032 CAT TOT: 100ms
033 CAT RTS: Enable
062 Data Mode: OTHERS
064 OTHER DISP (SSB): 1500 Hz
065 OTHER SHIFT (SSB):1500 Hz
066 DATA LCUT FREQ: OFF
068 DATA HCUT FREQ: OFF
070 DATA IN SELECT: REAR
071 DATA PTT SELECT: RTS
072 DATA PORT SELECT: USB
MODE: DATA -USB (NOT USB)
F (-LIST)
WIDTH: 3200
METER: ALC
RF PWR: 8-50W start low and work up.
WIDTH: NAR/WIDE: W 3000
AGC: Auto
NB-NOTCH-CONT-DNR-DNF: Off
DT Gain: 6
*** IMPORTANT *** The DT Gain defaults to 50! This will overdrive the rigs modulator which will cause unwanted audio harmonics. Not good. Turn the DT Gain setting down to about 4, and start working your way back up, watching for ALC on the meter as well as the power out that you want. As you move the DT Gain setting back up (higher), you will see your power level increase as well as ALC levels. Find the happy medium of NO ALC showing on the meter. Excessive ALC indication is a sign that the audio drive is too high, and distortion is most likely happening.
Chapters:
00:02 Introduction
01:41 Menu Settings
05:02 Setting the Mode
05:22 Function Settings
08:25 How to set your ALC
11:52 JS8Call Setting and Demo
12:59 WSJTx FT8 Setting and Demo
15:14 Summary and End Notes.
Thanks for watching. Please remember to Like, Share, Comment, and Subscribe
I’m not Batman
73 de Tom, ND3N
