Before printing a 3D model from an STL file, it must first be processed by a piece of software called a "slicer" which converts the model into a series of thin layers and produces a G-code file containing instructions tailored to a specific printer. Several open source slicer programs exist, including Skeinforge, Slic3r, KISSlicer, and Cura.
The 3D printer follows the G-code instructions to lay down successive layers of liquid, powder, paper or sheet material to build the model from a series of cross sections. These layers, which correspond to the virtual cross sections from the CAD model, are joined or automatically fused to create the final shape. The primary advantage of this technique is its ability to create almost any shape or geometric feature.
Printer resolution describes layer thickness and X-Y resolution in dots per inch (dpi) or micrometres (µm). Typical layer thickness is around 100 µm (250 DPI), although some machines such as the Objet Connex series and 3D Systems' ProJet series can print layers as thin as 16 µm (1,600 DPI). X-Y resolution is comparable to that of laser printers. The particles (3D dots) are around 50 to 100 µm (510 to 250 DPI) in diameter.
Construction of a model with contemporary methods can take anywhere from several hours to several days, depending on the method used and the size and complexity of the model. Additive systems can typically reduce this time to a few hours, although it varies widely depending on the type of machine used and the size and number of models being produced simultaneously.
Traditional techniques like injection moulding can be less expensive for manufacturing polymer products in high quantities, but additive manufacturing can be faster, more flexible and less expensive when producing relatively small quantities of parts. 3D printers give designers and concept development teams the ability to produce parts and concept models using a desktop size printer.
Fused deposition modelling (FDM) was developed by S. Scott Crump in the late 1980s and was commercialised in 1990 by Stratasys. With the expiration of the patent on this technology there is now a large open-source development community, as well as commercial and DIY variants, which utilise this type of 3D printer. This has led to a two orders of magnitude price drop since this technology's creation.
In fused deposition modelling the model or part is produced by extruding small beads of material which harden immediately to form layers. A thermoplastic filament or metal wire that is wound on a coil is unreeled to supply material to an extrusion nozzle head. The nozzle head heats the material and turns the flow on and off. Typically stepper motors or servo motors are employed to move the extrusion head and adjust the flow and the head can be moved in both horizontal and vertical directions. Control of this mechanism is typically done by a computer-aided manufacturing (CAM) software package running on a microcontroller.
Various polymers are used, including acrylonitrile butadiene styrene (ABS), polycarbonate (PC), polylactic acid (PLA), high density polyethylene (HDPE), PC/ABS, and polyphenylsulfone (PPSU). In general the polymer is in the form of a filament, fabricated from virgin resins. Multiple projects in the open-source community exist that are aimed at processing post-consumer plastic waste into filament. These involve machines to shred and extrude the plastic material into filament.
FDM has some restrictions on the shapes that may be fabricated. For example, FDM usually cannot produce stalactite-like structures, since they would be unsupported during the build. These have to be avoided or a thin support may be designed into the structure which can be broken away during finishing.
Content From Wikipedia
en.wikipedia.org/wiki/3D_printing
TISHITU
ISO: 9001-2008
RESEARCH AND CONSULTANCY CELL OF INDUSTRIAL APPLICATION
A Joint Accreditation System of Australia and New Zealand
Copyright © All Rights Reserved tishitu.org Reg No.08122629691/SSI
Accreditation No. M3111204IN
-~-~~-~~~-~~-~-
Please watch: "Lifi Communication by Arduino UNO Download Project"
youtube.com/watch?v=c4gC8dbaiZg
-~-~~-~~~-~~-~-
Tishitu explains
How to Print by 3d Printer
Before printing a 3D model from an STL file, it must first be processed by a piece of software called a "slicer" which converts the model into a series of thin layers and produces a G-code file containing instructions tailored to a specific printer. Several open source slicer programs exist, including Skeinforge, Slic3r, KISSlicer, and Cura.
The 3D printer follows the G-code instructions to lay down successive layers of liquid, powder, paper or sheet material to build the model from a series of cross sections. These layers, which correspond to the virtual cross sections from the CAD model, are joined or automatically fused to create the final shape. The primary advantage of this technique is its ability to create almost any shape or geometric feature.
Printer resolution describes layer thickness and X-Y resolution in dots per inch (dpi) or micrometres (µm). Typical layer thickness is around 100 µm (250 DPI), although some machines such as the Objet Connex series and 3D Systems' ProJet series can print layers as thin as 16 µm (1,600 DPI). X-Y resolution is comparable to that of laser printers. The particles (3D dots) are around 50 to 100 µm (510 to 250 DPI) in diameter.
Construction of a model with contemporary methods can take anywhere from several hours to several days, depending on the method used and the size and complexity of the model. Additive systems can typically reduce this time to a few hours, although it varies widely depending on the type of machine used and the size and number of models being produced simultaneously.
Traditional techniques like injection moulding can be less expensive for manufacturing polymer products in high quantities, but additive manufacturing can be faster, more flexible and less expensive when producing relatively small quantities of parts. 3D printers give designers and concept development teams the ability to produce parts and concept models using a desktop size printer.
Fused deposition modelling (FDM) was developed by S. Scott Crump in the late 1980s and was commercialised in 1990 by Stratasys. With the expiration of the patent on this technology there is now a large open-source development community, as well as commercial and DIY variants, which utilise this type of 3D printer. This has led to a two orders of magnitude price drop since this technology's creation.
In fused deposition modelling the model or part is produced by extruding small beads of material which harden immediately to form layers. A thermoplastic filament or metal wire that is wound on a coil is unreeled to supply material to an extrusion nozzle head. The nozzle head heats the material and turns the flow on and off. Typically stepper motors or servo motors are employed to move the extrusion head and adjust the flow and the head can be moved in both horizontal and vertical directions. Control of this mechanism is typically done by a computer-aided manufacturing (CAM) software package running on a microcontroller.
Various polymers are used, including acrylonitrile butadiene styrene (ABS), polycarbonate (PC), polylactic acid (PLA), high density polyethylene (HDPE), PC/ABS, and polyphenylsulfone (PPSU). In general the polymer is in the form of a filament, fabricated from virgin resins. Multiple projects in the open-source community exist that are aimed at processing post-consumer plastic waste into filament. These involve machines to shred and extrude the plastic material into filament.
FDM has some restrictions on the shapes that may be fabricated. For example, FDM usually cannot produce stalactite-like structures, since they would be unsupported during the build. These have to be avoided or a thin support may be designed into the structure which can be broken away during finishing.
Content From Wikipedia
en.wikipedia.org/wiki/3D_printing
TISHITU
ISO: 9001-2008
RESEARCH AND CONSULTANCY CELL OF INDUSTRIAL APPLICATION
A Joint Accreditation System of Australia and New Zealand
Copyright © All Rights Reserved tishitu.org Reg No.08122629691/SSI
Accreditation No. M3111204IN
-~-~~-~~~-~~-~-
Please watch: "Lifi Communication by Arduino UNO Download Project"
youtube.com/watch?v=c4gC8dbaiZg
-~-~~-~~~-~~-~-


![Half Wave Rectifier
Half Wave Rectifier
In Half Wave Rectifiertype, only one diode is used. Generally, a step-down transformer is used to provide the required secondary voltage. The transformer isolates the load from the line. This reduces the possibility of electric shock.In the positive half cycle of secondary voltage, the diode is forward biased for voltages greater than the offset voltage. The offset voltage is 0.7 V for silicon diodes and 0.3 V for germanium diodes. This produces a half sine wave of voltage across the load resistor.
In the negative half cycle, the diode is reverse biased. The load current drops to zero.
The load current is always in the same direction. This provides rectification.
Average Voltage = Vdc = Vp/π = 0.318 Vp
Where, Vp = peak value of voltage across secondary. The value of direct current, the diode can handle is called as ‘Current rating of diode’ (Io).
Peak Inverse Voltage – In the negative half – cycle, the diode is reverse-biased. All secondary voltage appears across the diode. The maximum negative (reverse) voltage appearing across the diode is called the ‘Peak Inverse Voltage’ (PIV). To avoid break down, the PIV must be less than PIV rating of the diode.
For half wave rectifier PIV = Vp.
Maximum efficiency of half wave rectifier is 40.6 %.
Advantages and Disadvantages of Half wave rectifier:
A half wave rectifier is rarely used in practice. It is never preferred as the power supply of an audio circuit because of the very high ripple factor. High ripple factor will result in noises in input audio signal, which in turn will affect audio quality.
Advantage of a half wave rectifier is only that its cheap, simple and easy to construct. It is cheap because of the low number of components involved. Simple because of the straight forwardness in circuit design. Apart from this, a half wave rectifier has more number of disadvantages than advantages!
Disadvantages of Half wave rectifier:
1. The output current in the load contains, in addition to dc component, ac components of basic frequency equal to that of the input voltage frequency. Ripple factor is high and an elaborate filtering is, therefore, required to give steady dc output.
2. The power output and, therefore, rectification efficiency is quite low. This is due to the fact that power is delivered only during one half cycle of the input alternating voltage.
3. Transformer utilization factor is low.
4. DC saturation of transformer core resulting in magnetizing current and hysteresis losses and generation of harmonics.
The DC output available from a half-wave rectifier is not satisfactory to make a general power supply. However it can be used for some applications like battery charging.
