Uploaded July 2020 | Updated September 2026, 2 weeks ago
Learn how to add a t-track stop block to your miter saw station, plus covers for your dust collection hood and a zero clearance insert plate! These upgrades to my miter saw station have been a long time coming! // Learn more about the JET 12" Sliding Miter Saw here : bit.ly/JETmitersaw
📦 Materials Used On The Miter Saw Station Upgrades (affiliate):
🔹 T-Track, T-Slot Bolt, Knob : rockler.com/17-piece-universal-t-track-kit
🔹 Tape Measure : rockler.com/self-adhesive-measuring-tape
🔹 Hairline Indicator : rockler.com/t-track-tape-measures-t-track-tape-measures
CA Glue : amzn.to/2WYoONd
Magnets : amzn.to/2WX3OGC
🛠 Tools Used On The Miter Saw Station Upgrades (affiliate):
♦️ JET Miter Saw : bit.ly/JETmitersaw
🟨 Powermatic Drum Sander : amzn.to/2ZFwZQd
Router : amzn.to/32MFF9w
Edge Guide : amzn.to/3hzUYXi
¾” Bit (for routing t-track grooves) : amzn.to/32QAghC
Table Saw : amzn.to/2WrrNMm
Push Stick : amzn.to/2XIvgFq
Calipers : amzn.to/3g02Hxd
Countersink Bit : amzn.to/3eX5GFE
Magnetic Screw Holder (for my impact driver) : amzn.to/2xGYPwD
Cordless Drill : amzn.to/2wOFM2S
Sjobergs Workbench : amzn.to/2s4mffP
📹 SUBSCRIBE : goo.gl/V5gcNJ
💰 SUPPORT ME : youtube.com/channel/UC-hTi9atsD6wAl2s46LpAVw/join
📲 FOLLOW CRAFTED WORKSHOP!
INSTAGRAM: instagram.com/craftedworkshop
FACEBOOK: facebook.com/craftedworkshop
TWITTER: twitter.com/craftedworkshop
PINTEREST: pinterest.com/craftedworkshop
SCRIPT :
My miter saw station build was one of the earliest woodworking projects on this channel and was by far the largest project I had untaken at that point. This miter saw station is based on Jay Bates’ popular design and it has served me well over the last four years.
That said, I never really got it set back up properly after I moved into my new shop about a year ago, and, after receiving this beast of a new miter saw from JET a few weeks ago, I decided it was finally time to give the miter saw station a few upgrades.
These upgrades included adding a t-track stop block system for making more accurate, repeatable cuts, adding removable panels to the saw opening to improve dust collection, and finally making a zero clearance insert plate for the new JET miter saw.
I got started by working on getting some t-track added to the work surface, and this was a fairly straightforward process of routing a few grooves to house the t-track pieces. I used an edge guide to ensure I had a nice, straight groove, and I did have to remove the maple trim on this left side before routing.
I snuck up on the depth and got to my final depth after two passes and ended up with a really nice, snug fit with the t-track just below the surface of the plywood.
I repeated the same process on the right half of the miter saw station, although I don’t really see myself using a stop block on this side very frequently, and then I could route another groove for the peel-and-stick measuring tape.
This tape, which I got from Rockler, is actually made of metal and is just thick enough to catch on boards as I slide them across the work surface, and I figured housing the tape in a shallow groove would also help the numbers keep from being worn off over time.
I initially routed the groove for the tape measure right next to the groove for the t-track, but I realized this wasn’t going to work with the stop block design I was planning to use. Because of this, I needed to re-route the groove, this time routing it about an inch and a half from the t-track groove. That extra groove wasn’t a problem, as it was shallow enough where it wouldn’t cause any issues.
Once again, I repeated the process on the right half of the miter saw station and also cleaned up that maple trim, which had seen better days, while I was at it using my low angle jack plane.
When I went to install the t-track, I realized I had actually mistakenly ordered the wrong type of t-track from Rockler, where I get all of my t-track, and had received pieces with no holes pre-drilled. Because of this, I needed to drill holes for my mounting screws and also countersink the holes so the screw heads would sit flush with the surface of the t-track
Of course, I didn’t have a small enough countersink bit on hand, so I just went ahead and got the t-track mounted in the grooves temporarily before coming back to countersink them later.
Since there wasn’t a ton of plywood left for the screws to thread into after routing the grooves for the t-track, I decided to add a little more strength to the connection by adding some CA glue before screwing down the t-track and this made for a rock solid bond.
