In this video, we will check out the WiFi throughput of the Beryl AX in 80MHz and 160MHz. The tests will be done with OpenSpeedTest and iPerf3.
This is a WAN to LAN test. The Beryl AX is connected to the upstream router with a 2.5Gbps Link Speed. The PC is connected to Beryl AX with the Intel AX210 Wi-Fi 6E module. The OpenSpeedTest and iPerf3 server is running on the WAN side. No advanced configuration is done, the Beryl AX is running stock OpenWrt firmware from GL-iNet.
The result is very interesting. After the bandwidth changed to 160MHz, the Link Speed between the PC and the Beryl AX is now 2402Mbps. The OpenSpeedTest result is closed to 2Gbps while iPerf3 throughput is 1.3Gbps.

Video timeframe:
00:00 - Intro
01:25 - WiFi Throughput in 80MHz (default configuration)
02:00 - Change the 5GHz WiFi bandwidth to 160MHz
03:08 - WiFi Throughput in 160MHz - OpenSpeedTest
04:18 - WiFi Speedtest & CPU Usage Overview
05:34 - WiFi Throughput in 160MHz - iperf3

Beryl AX Unboxing & Review - youtu.be/1is6m-xBeKY
The Beryl AX is available on the GL-iNet Webstore - bit.ly/3HAS18M
You can also find in on Amazon amzn.to/3Jj6cjO

Thanks for watching and see you in the next video!
