Uploaded May 2026 | Updated September 2026, 2 weeks ago
Dive into the workflow of advanced tire modeling using the Extended Tire Features in Vehicle Dynamics Blockset™. Learn how detailed tire data can significantly improve the accuracy of vehicle dynamics simulations—especially under nonlinear conditions such as combined slip, varying vertical loads, and camber effects.
After a brief overview of tire forces, moments, and angles, walk through a complete, programmatic workflow for working with tire data. You’ll see how to import and preprocess data from formats such as TYDEX, MAT-files, and other common sources, visualize tire behavior, and fit a Magic Formula 6.2 tire model using MATLAB®. Demonstrations will show you how to calibrate tire models, inspect fitting results, and export them into formats compatible with Simulink® vehicle models.
You’ll also learn how to integrate the fitted tire model directly into Vehicle Dynamics Blockset tire blocks, run vehicle simulations such as skidpad tests, and evaluate the impact of different tire models on overall vehicle handling. Finally, you’ll take a brief look at the Tire Manager app, offering an alternative workflow for fitting and deploying tire models.
This video is ideal for engineers and student teams working on vehicle dynamics, motorsports, or Formula Student simulations who want to build more realistic and reliable tire models.
Learn more:
- Get Started with the Extended Tire Features for Vehicle Dynamics Blockset: bit.ly/48tw3BB
- Fit Tire Models with the Tire Manager App: bit.ly/4ddl8i2
- tireData.import: Import Tire Data from Different Formats: bit.ly/4mZIQ4P
- Fit Type: tireModel.fit: bit.ly/3QEJzfE
- Wheels and Tires — Functions: bit.ly/4t7o0BR
- Generate Skidpad Test: bit.ly/4fUEqGZ
Chapters:
3:02 Introduction to Extended Tire Features
4:26 How to Import Tire Data
5:17 How to Plot and Visualize Tire Data
7:50 Fit Tire Data
12:19 Export Tire Model to Simulink Model
13:58 Formula Student Tire Modeling for Lateral Data
17:22 Glimpse of Tire Manager App
--------------------------------------------------------------------------------------------------------
Get a free product trial: goo.gl/ZHFb5u
Learn more about MATLAB: goo.gl/8QV7ZZ
Learn more about Simulink: goo.gl/nqnbLe
See what's new in MATLAB and Simulink: goo.gl/pgGtod
© 2022 The MathWorks, Inc. MATLAB and Simulink are registered trademarks of The MathWorks, Inc.
See mathworks.com/trademarks for a list of additional trademarks. Other product or brand names may be trademarks or registered trademarks of their respective holders.
