Uploaded March 2026 | Updated September 2026, 4 hours ago
Raceweek is coming in hot, and that means every weak link in the Chevelle's cooling system has to go. In this video, we ditch the factory integrated radiator transmission cooler and install a fully standalone Derale transmission cooler plumbed with PTFE braided AN lines — the right way to cool an automatic transmission under race conditions.
This is a complete standalone transmission cooler install guide for a TH350 automatic, but the process applies to any GM automatic running AN fittings. We cover the specific straight-thread vs. NPT fitting differences, correct AN adapter sizing for the TH350 ports (with part numbers), and a crucial tip about sharp frame edges that will destroy your lines if you miss it.
What's covered:
🥓 Why you should never rely on radiator-integrated transmission cooling
🥓 Standalone transmission cooler mounting with radiator ties
🥓 TH350 transmission fluid port fittings — NPT vs. NPS vs. straight-thread explained
🥓 PTFE braided line routing and measuring technique
🥓 Grinding sharp frame edges to protect lines from vibration damage
🥓 Minimal fluid loss during install (and why it drains to the pan)
🥓 Full system test and fluid check after install
We aren't done yet — engine oil cooler is up next! Make sure you subscribe so you don't miss the rest of this Raceweek prep.
📢 OneMoreBolt Swag 📢
🔗 onemorebolt.printful.me
🛠️ Parts & Discounts in this Video:
📌 Transmission Cooler
🔗 amzn.to/4lKe27u
📌 ICT Billet Transmission Fittings:
🔗 amzn.to/4bG3QZ1
📌 Evil Energy 6AN PTFE Line Kit
🔗 amzn.to/4d8rmAp
Amazon Links are Affiliate links and I may earn a commission.
🍿 How to Assemble Evil Energy PTFE AN Lines – Easy Step-by-Step Guide!
🔗 youtu.be/9YyyR7yS7OU
⏱️ Video Chapters (Follow Along):
0:00 - Intro
0:08 - The Raceweek Cooling Problem (Big Block Heat)
1:41 - The Old Setup (Stainless Hard Lines = Pain in the A**)
2:54 - Transmission Fittings (NPSM to 6AN)
4:48 - Mounting the New Transmission Cooler in Free Air
8:03 - Routing PTFE Braided Lines
15:12 - New Lines Complete Final Plumbing & Securing the System
19:35 - Firing the 454! (Leak Checks & Big Block Sounds)
24:45 - Is That a Puddle? What’s Next? (Engine Oil Cooler Tease)
