Multilayer Downskin Surface Optimization

Uploaded April 2026 | Updated September 2026, 1 week ago

Printing overhanging features in laser powder bed fusion presents challenges for surface quality, as downskin layers are built on loose powder rather than solidified material. This FLOW-3D AM simulation demonstrates multilayer IN718 LPBF printing at a 45-degree angle, used to optimize downskin surface roughness. CFD modeling helps engineers identify process parameters that improve as-printed surface finish on overhanging features. Learn more at flow3d.com/products/flow3d-am
