Tesla Magnifier Radiant Energy Experiment Teslas Primary Ray Research 2020-12-13 | This is another experiment I've been wanting to replicate since I first saw some of Eric Dollard's videos on radiant energy.Does this have anything to do with gravity? Does the sun work like a resonant system, beaming energy to earth while also holding it within its gravitational field?Gravity may be a force much different than what we've imagined it to be.
Tesla Magnifier Output Turns Crookes Radiometer within Discharge Area Teslas Primary Ray Research 2020-12-13 | This is something I had been trying to replicate for a number of years.The Crookes Radiometer has had many different theories. It was originally invented in the 1870's by Sir William Crookes. He originally thought that it was turning based on the 'pressure' of light radiation. It is now commonly understood to turn based on the black side of the vane making heat when light hits it, and thus turning the vanes around due to air currents. The direction of this radiometer's vanes spins clockwise in sunlight as you would expect from the black paint that coats one side of the vane. The black side typically moves away from the direction of sunlight.It is assumed that it has to be air currents from heat generated. If the bulb is entirely evacuated of air, the vanes cease to turn.Here we see the vanes turn with no source of light, but instead placed within a high intensity electric field. The stronger the field and more ions that are driven between the high tension field, the faster the vanes turn.
Thyratron Switched Tesla Magnifier System Teslas Primary Ray Research 2020-12-12 | An introduction to a new system I've been working on as a platform for experimentation.This is a HVDC system operating around 7500 volts DC. It is only capable of delivering around 300-400 watts of power. Instead of a typical spark gap, there is a 5C22 thyratron driven by an EG&G TM-29 Thyratron Grid Driver. The goal of this system is to create a very instantaneous disruptive discharge into the primary system for damped wave oscillation. The energy is dumped into the primary which is magnetically transferred into the secondary coil. This secondary coil then drives a high voltage and high current into the small extra coil. The small extra coil has no magnetic coupling to the primary or secondary so once the energy is transferred the extra coil rings freely. This allows it to generate higher voltages than the input voltage coming out of the secondary coil. I can also completely short out this system with no chance of damaging the system or pulling too much current.Ive built countless systems and broken many hundreds of dollars worth of transistors and IGBTs. In search of a system that cannot break, I decided to build out a thyratron switched tesla magnifer system.You can find out more about my journey tuning this system on my new website www.evolvedaether.comThanks for watching!
The First International Conference on Future Energy - Betavoltaic Batteries - Dr. Paul Brown 1999 Teslas Primary Ray Research 2020-11-30 | ...
Radioisotopic Energy Generation - Paul Brown - International Tesla Symposium 1990 Teslas Primary Ray Research 2020-11-30 | ...
Vortex Driven Tesla Magnifier Teslas Primary Ray Research 2014-11-18 | Intro to understanding the magnifier theory and how it works. Questions welcome.
Radiant Energy Oscillator Teslas Primary Ray Research 2014-04-25 | This is by far the best circuit I have tried, I have tried many of the circuits from Nikola Tesla's CO Springs Notebook...Many are symmetrical, some are hard to tune and some are not. The ones that are selective and hard to tune are also very efficient...The trade off is in the power dissipated. The easy to tune ones may require lots of current to get power into the other circuit. This is because the system is out of balance. This circuit requires a bifilar choke, a tuning inductor and gas discharge tubes. The capacitors are also necessary for the tight tuning. There is much complexity in this circuit and it must be properly matched so that the whole system is in resonance. I have posted the equations on my website some time ago. This is kind of like a resonant DC buck converter, with 2 different circuit analysis...one for when the discharge happens and is temporarily shorted, and the other for charging. The impedances change with respect to what circuit configuration exists. The voltage breakdown of the spark is also a key figure. I would recommend getting a bunch of HV HF diodes, a ranges of voltages for gas discharge tubes and a variable inductor. The output is mainly dependent on the conditioning of energy before it even gets to the primary of the tesla type vortex coil...The frequency of the "bursts" from the discharge must be tuned accordingly. The significance of the bifilar choke is that when in a LC system, the phase angle is around -90 degrees no matter what! The LC system seemingly has no inductance, so the phase is kept that of a capacitor, so it can then be balanced by the primary inductance of the vortex coil and tuned with the variable inductor. IF the choke was not bifilar, tuning would be even more selective...not to mention much more frustrating!The gas discharge tube (GDT) that worked best was for me was 800v...the frequency of the discharge depends mainly on the amount of power delivered from the iron core transformer and the breakdown voltage of the GDT. The lower the voltage breakdown, the faster the spark frequency.
Tesla Style Oscillator and Induced ground currents Teslas Primary Ray Research 2014-04-22 | Been diving into some new circuits...None have proved to be more efficient than running it directly with the solid state oscillator...however there are some effects that are only noted at higher voltages like the green discharge...
Resonant Buck Converter Radiant Circuit Teslas Primary Ray Research 2014-02-21 | After noticing tesla's schematics resembled a buck converter, I decided to make a resonant buck converter with the path to ground being my coil. Needless to say, the circuit performs much better with higher efficiency.Book is Nikola Tesla's Colorado Springs Notebook
Further Analysis of Spark Gap to Capacitance Teslas Primary Ray Research 2014-02-12 | At first when I saw this I decided that the frequency of spark had to be a naturally occurring frequency. But this was irrespective of the driving frequency and the natural frequency of the coil. I then found out the spark frequency was the same as the pulse width of the square wave....Any ideas of how to stop this from happening? Can this be of any benefit?
Investigation of extra spark to capacitance Teslas Primary Ray Research 2014-02-11 | In tesla's magnifying transmitter schematic, he employs an extra spark from the top of the secondary to a large capacitance...There seems to be a benefit here that may be largely misunderstood. Either way, a spark to a capacitance causes a magnification of radiant energy in the whole circuit, all the way back into the primary and into the driving circuit. The better your driver is at blocking this energy from leaking back into ground via gate capacitances and blocking diodes the more energy will be conserved in resonance. The use of employing a blocking cap and light bulb to ground from the primary is a way of draining the energy from going back into your driving circuit. This is not necessarily beneficial (as you want the energy to stay in the resonant system) but it does ease the workload on the blocking diodes...sometimes the radiant causes my circuit to self oscillate at a high frequency, most likely due to the small wires in my driving circuit forming capacitance's and causing miscellaneous oscillations. This is also not good, as this frequency is usually not the resonant frequency!
The Evolution of Teslas Transmitter Teslas Primary Ray Research 2014-02-03 | NOTE: This is not tesla's true wireless because these coils have distributed capacity requiring the need for a coupling capacitor. Tesla had a node at one end of the coil and maximum amplitude at the end that was grounded. The toroid was used as a method of reflecting the wave back down into the earth. These vortex coils have maximum amplitude at both ends of the coil. Here we go into the phenomenon of glowing discharges and capacitive coupling to earth. What exactly is radiant energy? How does it prefer to travel? This shows a replication of a transmitter that goes from a spark to earth to a capacitive coupling to earth. This is my efforts in replicating Nikola Tesla's experiments in his CO Springs Notebook. Also, when the glow discharge happens, it seems the excited portion of air is excited closest to the ground electrode...The coil seems to create an "area" of low potential in reference to earth. The earth is responding to the vibrations of harmonic resonance with radiant energy. This could have to do more with mass than capacitance.
Breakdown of Air into a Conductor via Radiant Energy Teslas Primary Ray Research 2014-02-01 | Showing an experiment of how breakdown of air can lead to a glow like discharge that can transmit current at HF.
Driving two receiver coils at resonance Teslas Primary Ray Research 2014-01-29 | Here we can see how two coils can be driven via the ground and a capacitance. Each receiver coil has its own capacitance. When a coil is added it does shift the resonant frequency slightly, thus when a coil is added, it becomes out of tune...so I tune it back into resonance...This is not overunity, but I am showing how the energy that is transferred into the ground can be multiplied. Only in resonance with the earth do the laws of music apply to electricity.
Water Spark Gap Teslas Primary Ray Research 2014-01-13 | I tried using the larger coil as a driver, and the double vortex coil as an extra coil with a capacitance and a spark gap like tesla did. Then I got this weird result. I would appreciate some feedback as I dont think the meter could actually be right...could it?
Process of tuning into resonance Teslas Primary Ray Research 2014-01-12 | By analysis of the damped waveform of a coil, the resonant frequency can be calculated. The coil however will resonate at various multiples of this fundamental frequency. When the space between pulses is shortened, the damped waveforms then begin to interfere with each other.(Also the music has nothing to do with the waveform but it does look and sound pretty cool)
Wave form analysis of Dual Inter-weaved Torus vs conventional Rodin Coil Teslas Primary Ray Research 2013-12-25 | With a 13.8 volt supply I was able to achieve 2 times the voltage gain on the dual inter-weaved torus (DIT) in comparison to the conventional rodin coil (RC). Interesting things to note have to do with how the conventional RC is half the length of wire as the DIT. Also the resonant frequency of the DIT is half that of the RC...Thus we produce 2 times the voltage on the DIT compared to the RC....What do you think this has to do with?The lower resonant frequency produces a much larger EM field and pretends it is a huge antenna. (the DIT is resonant around 23khz and the RC is around 46khz) I personally have a hunch that these coils are reaching into the zero point field through fractal geometry.Now because the wavelength of the DIT is 2 times larger than the RC....would you think the voltage gains could be due to closer resonance with earths resonant frequencies? In Tesla's CO springs notebook he achieved huge voltage gains with bigger coils (same power supply)....thus larger wavelengths/lower frequencies....I would lean towards the interaction the coil has with its environment for reasons of larger voltages and longer damped oscillations rather than ratios of primary to secondary windings...after all the DIT and the RC are both the same ratio of length of wire to each other along with mass of copper. Many variables are held constant between these two coils. Feedback is much appreciated. There is something to be said of Tesla's experiments at CO springs...particularly the amount of time he spent adjusting the wavelength of the transmitter by adjusting the capacitance and spark frequency...could the transmitter have been tapping into a frequency/harmonic of earth thus getting larger voltages? I am beginning to think so. Try and look up info on tesla's relations with ELF and VLF frequencies. It gets weird really fast.
Longer Distance Transmission of Electricity via capacitive coupling Teslas Primary Ray Research 2013-12-13 | ...
Resonant Transmission of Electricity with Pulsed DC via Vortex Coils Teslas Primary Ray Research 2013-12-13 | ...
Single Wire Transmission with Asymmetric Motor powering Vortex Coils Teslas Primary Ray Research 2013-12-12 | In this video I show Tesla's original idea applied to vortex coils. The vortex coils are based off of Tesla's equations for resonance...(same mass in both primary and secondary winding's). The coils are made to be out of phase with each other, this is accomplished through winding the coils in opposite geometry to each other as shown. These coils are both resonant around 47.8khz. They each have about 109m of wire on the secondaries. I also have used a meter to calculate the inductance. This resulted in a proposed resonant frequency of about 25khz with a microwave capacitor....My guess is because of the distributed capacitance they will resonate at a range of frequencies....however when pulsed at around 50khz, I calculated a voltage gain of 20. Using a signal generator set to a square wave at 20vpp @ ~50khz the coil goes into harmonic oscillation with ~400vpp. This is the desired driving frequency. With AC the coil will produce AC radiant waves. With DC pulses I believe it will be able to make damped oscillations in purely negative or positive depending on the polarity. With the use of an elevated terminal and high voltage, these coils can push power through the ground very efficiently. Only through resonance will they be able to receive the power. Because of the asymmetric motor, I am causing the coil to go into resonance with excitation of the radiant energy that is coming out of the generator side of the motor. This can also be accomplished through a spark gap into the coil. I am convinced all tesla's generators were ASYMMETRIC. Another interesting thing is how his westinghouse transformer was wrapped if he was indeed using AC from the power mains. This transformation of energy can only be done through asymmetric systems. Through the use of high voltage and elevated terminals, electrons can be caused to move in accordance to the pressure (voltage) exerted on them. Thus your source of electrons becomes the environment (various metals to be specific). This has to do with MASS.
Energy Transformation through Asymmetric Sytems Teslas Primary Ray Research 2013-10-21 | This video is intended to inspire others to experiment both mentally and physically with the idea of asymmetry. There is no magic, it is simply the breaking of symmetry that lets radiant energy manifest itself. You cannot measure it with our standard tools. This energy can only be shown and felt. It has deep roots in the geometry of nature. Nature always responds to changes in energy density with a vortex/spiral movement. Look at hurricanes, storms, sound, whirlpools, and tornadoes for example. Is it too far fetched to think when a magnetic field is created, the environment responds in a similar manner with an opposing vortex? Every time we create a magnetic field on our side of reality, an opposing one is made from the environment. This is what makes negative EMF spikes in pulsed systems (however we are taught in depth of how to FILTER it out). If the system is symmetric, the opposing field will directly cancel out with the field we create resulting in heat generation. This is our current standard for energy efficiency. An asymmetric system allows the field to be created without direct canceling of the magnetic fields resulting in an environmental magnetic oscillation, which can deliver energy. This is the idea behind the rodin/vortex/abha coil. Everything is already resonating. The geometry exists in the mind before it is physically represented. I encourage anyone who is interested to put an idea together, and then WORK on it. If you want to build an asymmetrical motor/generator go to:http://www.energeticforum.com/renewable-energy/11885-my-asymmetric-electrodynamic-machines.htmlHeres a link to a picture showing the key difference in asymmetrical vs symmetrical motors:http://s1251.photobucket.com/user/ufopolitics/media/SYMMETRIC_ALEXANDER_DYNAMO_ASYMMETRIC.jpg.html?sort=3&o=153If you want to build a rodin coil, do it. Here is a video from Daniel Nunez showing how I made the wires to wrap the frame I had fabricated.youtube.com/watch?v=FiGH4zRsO0UEmail me for a PDF of the cut outs. I am happy to explain what I know and answer questions regarding asymmetry. I am open to all criticisms and ideas. This is the energy Tesla was working with. It is related to the Schumann resonances, which are related to radioactivity and solar winds coming from the sun. In short this energy is related to the cosmos. It contains all harmonics. It is scalar in nature. It travels faster than the speed of light. We are not given the tools to measure it. It can only be seen and felt. Om Namah Shivaya (Earth Water Fire Air and Aether)
Output of Asymmetric Motor into Tesla Style Rodin Coil Teslas Primary Ray Research 2013-10-17 | Here the output of the asymmetric motor is first analyzed on a scope to see the PWM output. The asymmetric motor is known to output DC, however there is another component to the output... The rodin coil is then connected and the waveform is analyzed once again. When a ground is connected to the rodin coil through capacitors and LEDs in series we can see that there is AC power present between the coil and the ground. When more capacitance or a source of radiant is connected to the hot end of the secondary we can see an increase in power flow from the ground into the coil to the top connection of the secondaries. By exciting the coil with radiant energy we can create a path for radiant energy to flow from the ground into the atmosphere (space the coil occupies). The main reason I am showing this is because this is not possible with any form of symmetric system. Symmetric motors/systems comprise everything available on the market.
Resonance vs Capacitance of Tesla style Abha/Vortex/Rodin Coil Teslas Primary Ray Research 2013-10-15 | A square wave is pulsed through a vortex coil via signal generator. A microwave oven capacitor is in series with the input. Due to this, the square wave smooths out at higher frequencies. Interesting things learned were the resonance seems to be independent of wire length. I will be making a smaller one the same way and testing the resonance of that as well. The lower frequency of vibration at resonance and the geometry of the coil allows the coil to capture energy by oscillating with the environment.
Generator output test of asymmetric motor Teslas Primary Ray Research 2013-02-21 | Pulsed with 13.8 volts. No step up transformers.
Asymmetric motor pulsed with audio signal +radiant energy circuit Teslas Primary Ray Research 2013-02-20 | ...
Asymmetric Scooter motor with output voltage Teslas Primary Ray Research 2013-02-19 | running on 13.8 volts parallel input with 18.0 volts series output
Asymmetrical Radio Shack motor with radiant energy circuit + schematic Teslas Primary Ray Research 2013-02-19 | The schematic at the end is drawn with 2 rodin coils on opposite sides of the pancake coil. Both coils however are wrapped around the same pancake coil as shown in the video.
Dual Pentagon RS asymmetrical modified motor Teslas Primary Ray Research 2013-01-26 | Here I show the radiant output from the motor.
Radiant energy lights up neon purple experiment #2 Teslas Primary Ray Research 2012-12-18 | This is done by pulsing a car ignition coil with 6 volts
Radiant Energy lights up neon Teslas Primary Ray Research 2012-12-18 | With the addition of a capacitor the neon changes from a more radiant purple to an orange. Could the capacitor be acting as some sort of storage bank and in turn altering the type of particles flowing through the neon gas?
UFO pwm neon experiment Teslas Primary Ray Research 2012-12-18 | depending on frequency and duty cycle, a purely purple radiant light can be seen. This is one of my first runs...will be mounting more FET's soon and getting a bigger coil.
SEC driven with rodin coil as L2 Teslas Primary Ray Research 2012-12-06 | I have been doing a lot of work lately on trying to figure out how different inductors have different collapses of their magnetic fields resulting in the cold electricity/radiant energy effect. Most L2's have sharp tuning when they are regular inductors. caduceus and rodin coils are not limited to this at all. they are more freely resonating. Thus they can stimulate other coils better. I also made a bifilar pancake coil much like tesla's patent and it is also very sharp in tuning. (which is what the purpose was I believe) bottom line is... these coils are different. Try it.
Sec exciter charges battery with solar panel UPDATE Teslas Primary Ray Research 2012-12-05 | Please feel free to post comments and questions.
Sec exciter barely on, still charges battery with aluminum block Teslas Primary Ray Research 2012-12-04 | ...
SEC exciter charges battery with solar panel Teslas Primary Ray Research 2012-12-04 | Here I have a new circuit I built that allows me to adjust the frequency at which the circuit operates and a way to adjust the amplitude of the frequencies through the coil according to my spectrum analyzer.
SEC exciter regenerative reciever lights up neon Teslas Primary Ray Research 2012-11-30 | a Passive SEC circuit stimulated by the excitation of another. I can generate a higher voltage on the PSEC than what my Powered SEC circuit can deliver. Here I am showing it light up a neon with the radiant energy it is collecting when tuned correctly. Not sure why it only does it for a few times after reversing before it goes to orange. It seems it has to condition the electrodes before they will produce the regular orange glow.
Dr. Stiffler SEC replication with PSEC Teslas Primary Ray Research 2012-11-16 | A driver circuit is hooked up to a solar panel. When tuned to a certain frequency, the circuit shuts off (stops oscillating) but the coils are still being excited? Only when I have a PSEC circuit hooked up to the excited coils, it stays excited. I would call this a PSEC or potential driven sec exciter. They are somehow tied together.
