Gallus KM 410 in-line folding carton uv-flexo press with
FSM 410 flatbed cutting & creasing unit
Year of Manufacture: 2001
Reelstand
Infeed
7 Print units FLEXO with UVI dryer
Web edge control
Console Sensotec Monitor
Video web control
Die-cutting in delivery with belt
2 Ink pumps electrically
8 Chill rollers
Automatic Ink control register Escope 300
Max. width of material: 410 mm
Max. width of impression: 390 mm neto
Carton weight: 135 – 450 gr./m²
Carton thickness: 0,3 – 0,65mm
Circumference variable
Cylinders type Sleeves or with plates
Max. speed: 120 meters/minute
Print repeat range, with easy-change and adjustable impression cylinder. prepared for using printing sleeves water cooled transport rollers sensotec full automatic register control
Gallus FSM410 flatbed cutting & creasing unit. completely servo driven. second de-curling unit in front of flatbed die cutter. shingle delivery for blanks
