Drilling 10 holes into a block-o-POM, one far too large for the mill …
↓↓↓ Complete description, time index and links below ↓↓↓
Last time we milled a POM block square and to the principle dimensions. We also scribed markings for the following operations into it (link below). Now it’s time for the ten drilling operations … and things won’t go as planned.
We start out easy with four 3.3mm holes. A single 8mm in between hole gives us a hint of things to come. The next four 5mm holes go in effortless again. Finally we drill a 16mm hole in 10 steps, which initially went in like a dream, but …
00:00 Intro – let’s drill a lot of holes
00:31 Forecast – gloomy message from future Robert
01:15 Overview – just ten holes to drill
03:22 Drilling (1) – four 3.3mm holes into the back
05:39 Drilling (2) – one 8mm hole into the back
08:30 Drilling (3) – four 5mm holes into the front
10:53 Change – of setup for 16mm hole (column too short)
15:17 Drilling (4) – first six steps for the 16mm hole
20:34 Off-center – with the hole, actually quite a bit
23:57 Trigonometry – small angular errors can be terrible
28:36 Drilling (5) – last four steps for the 16mm hole
38:50 Torqued-out – on the last 20mm with the 16mm drill
41:42 Result – 16mm hole still a bit off-center and unfinished
44:01 Wrap-up – 16mm hole will be finished another day, bye
