SMD Soldering - QFN Package Androkavo 2017-12-30 | SMD Soldering - Hand Soldering - QFN Package (WQFN48)
DIY 18650 Battery Charger and Voltmeter Androkavo 2018-10-30 | DIY 18650 Battery Charger and Voltmeter by Flexible PCB from PCBWay : pcbway.comBattery sizes : 21700, 26650, 18650, 14500Maximum charge current : 0.8AVoltmeter : 2.7 ~ 5.5VDownload Project (gerber, schematic, images, ...) : pcbway.com/project/shareproject/18650_Battery_Charger_and_Voltmeter.html
One Hit Desoldering Androkavo 2018-09-22 | Desoldering without hot air & as fast as possible with desoldering tipsTools used in videoSoldering Station: FX-951Soldering Iron: FM-2028Soldering Tips: T12-BCF3/K/1403/1006/1001/1003/1207Flux: Mechanic MCN-UV50Solder wire: 63/37 0.8mmMicroscope: Andonstar ADSM201Temperature: 315 ~ 400°C (depend on size of components and heatsink area on PCB)Note: in North America & EU, soldering iron FM-2028 and tips T12 series switch to FM-2027 and T15 series, shape of tips are same.All soldering tips of T12 series : http://www.hakko.com/english/tip_selection/series_t12.htmlBuy at Distributors of Hakko : http://www.hakko.com/world_network.html
Desoldering without hot air Androkavo 2018-08-15 | Desoldering without hot air and desoldering toolsTools used in videoSoldering Station: FX-951Soldering Iron: FM-2028Soldering Tips: T12-K, T12-BCF2/BCF3Flux: Mechanic MCN-UV50Solder wire: 63/37 0.8mmOther: Copper wire 0.6mmMicroscope: Andonstar ADSM201Temperature: 315 ~ 400°C (depend on size of components and heatsink area on PCB)Note: in North America & EU, soldering iron FM-2028 and tips T12 series switch to FM-2027 and T15 series, shape of tips are same
DIY Wooden Lamp Androkavo 2018-08-01 | $2 for 10 Prototype PCBs + 2 days Lead Time at jlcpcb.comDIY Wooden Lamp with Touch sensorDownload Gerber, schematic, parts list : drive.google.com/file/d/1tIbF4ZhkkpR5hXVfcP05iEojqDqZm7NJ/view
Hakko FX-951 Soldering Station Androkavo 2018-07-21 | Review Hakko FX-951 Soldering Station (FX951-55) version 220V with soldering iron FM-2028http://www.hakko.com/english/products/hakko_fx951.htmlFor avoid Counterfeit products, i recommend buy at Head Office or Distributors of Hakko : http://www.hakko.com/world_network.htmlThis soldering station used forsoldering QFP176 Package : youtu.be/09qb0KY_IF4and Smallest Package : youtu.be/P72U2yHWKSk
How to fix Mouse Double Click Androkavo 2018-06-14 | Why mouse double click and how to fixLimit Switch : goo.gl/JT8VftOMRON Mouse Switch : goo.gl/zkLejL
SMD Soldering - Smallest Package Androkavo 2018-06-04 | $2 for 10pcs PCBs & $7 for a SMT Stencil at jlcpcb.comAn online price calculator and the order form is available at this link: jlcpcb.com/quoteI'm testing bigger tip with three tiny parts to see what happens, you should use smaller tip with smaller parts for easierSMD Soldering - Hand soldering packages : 0603, 0402, 0201, 01005, 008004Soldering tip T12-C1, 315°CSolder 63/37Paste Flux Mechanic MCN-UV50/UV80 (different weight) : goo.gl/zSSyHdBottle Dispenser : goo.gl/w7n3zAPaint Brush : goo.gl/5mzXtRMicroscope Andonstar ADSM201 : goo.gl/5gUDf6
SMD Soldering - QFP176 Package Androkavo 2018-05-28 | $2 for 10pcs PCBs & $7 for a SMT Stencil at jlcpcb.comAn online price calculator and the order form is available at this link: jlcpcb.com/quoteSMD Soldering - Hand soldering - QFP176 PackageSoldering tip T12-BCF2, 315°CSolder 63/37Paste Flux Mechanic MCN-UV50/UV80 (different weight) : goo.gl/zSSyHdBottle Dispenser : goo.gl/w7n3zAPaint Brush : goo.gl/5mzXtRMicroscope Andonstar ADSM201 : goo.gl/5gUDf6
JLCPCB Complete Guide: How to Get Your PCB Manufactured Androkavo 2018-05-15 | $2 for 10pcs PCBs & $7 for a SMT Stencil at jlcpcb.comIn this video I will review JLCPCB, the largest China manufacturer of prototype and small-batch PCBs. I’ll show gerber generation, the ordering process, price, shipping, quality, and the boards/stencils I received. An online price calculator and the order form is available at this link: jlcpcb.com/quote
Solder wire test - Mechanic Sn42/Bi58 Androkavo 2018-04-23 | Lead-free Mechanic Sn42Bi58 : goo.gl/G7UPPJ
How to clean Soldering Tip Androkavo 2018-03-14 | About sandpaper, use only sandpaper grit 600 1000 1500 or higher (called High grit, Ultra fine sandpaper)- wrong way : sandpaper (low grit) with high pressure like abrasive, sander machine- correct way : sandpaper (600+) with low or enough pressure by finger
Solder wire - Low Quality Lead vs Lead Free Androkavo 2018-03-03 | Previous video : youtube.com/watch?v=5Ku7I3hA3AA
Solder wire - Low vs High Quality Androkavo 2018-02-25 | - Cheap solder, it's Not 60/40 alloy, maybe 10/90 or other alloy for reduce cost- Some good brands : Asahi, Electroloy, Lodestar, Mechanic, Kester, ...Asahi : goo.gl/kzRtrsElectroloy : goo.gl/NTNJLULodestar : goo.gl/r8g2ytMechanic : goo.gl/dXzFDnKester : goo.gl/mxkirHMusic : Good Starts - Jingle Punks, Daily Beetle - Kevin MacLeod
How to repair bridge and excess solder Androkavo 2018-02-14 | Paste Flux Mechanic MCN-UV80Solder Wick : Goot wick CP-2515Soldering Tips : 900M-T-2C, 900M-T-4C
When to use Flux ? Androkavo 2018-02-06 | Paste Flux Mechanic MCN-UV80Clean flux with alcohol and paintbrush/toothbrush/wipe
How to repair cold solder joint Androkavo 2018-01-30 | Paste Flux Mechanic MCN-UV80 : goo.gl/zSSyHdClean flux with alcohol and paintbrush/toothbrush/wipe
Solder Alloys Test - Lead and Lead Free Solder Androkavo 2018-01-19 | Solder Alloys Test - Lead and Lead Free Solder : 60/40 - 63/37 (Eutectic) - 99.3/Cu0.7 - 99/Ag0.3/Cu0.7 (SAC) - 96.5/Ag3/Cu0.5 (SAC305)- 60/40 and 63/37 shiny like mirror, experiment when soldering is same and price near similar, if you want low price choose 60/40- 99.3/Cu0.7 (#1), 99/Ag0.3/Cu0.7 (#2), 96.5/Ag3/Cu0.5 (#3)#2 and #3 shiny like aluminum (similar aluminum case of macbook), #1 shiny like fusion between mirror and aluminum. If you want use lead-free and shiny like lead, choose #1- Temperature soldering #1 #2 similar, #3 lower a little bit. So, feel when soldering #3 easy a little bit than #1 and #2- Price #1 #2 near similar, price #3 approximate double of #1- #1 #2 #3 need high temperature when soldering, so have risk that can damage chip if you hold soldering iron for long time- if you want use lead-free and no problem with money, choose #3 and soldering as fast as possibleSo, choose Lead or Lead Free ?Nothing is perfect. My conclusionsLead : best for solderingLead Free : best for health & environmentI recommend use Lead Solder, except your application require RoHS or you care about health & environment
SMD Soldering - Common Packages Androkavo 2018-01-12 | SMD Soldering - Hand Soldering - Common Packages : Resistor Array, SOT23-6, SOT23-3, SOT89, SOT223, TO252 (DPAK), TO263 (D2PAK), TO263-5, Mini PushButton, Crystal HC49, Aluminum Capacitor, Power InductorPaste Flux Mechanic MCN-UV80 : goo.gl/zSSyHdBottle Dispenser : goo.gl/w7n3zA
SMD Soldering - PLCC Package Androkavo 2018-01-03 | SMD Soldering - Hand Soldering - PLCC Package (J-Lead PLCC44)
SMD Soldering - SOIC SSOP Packages Androkavo 2017-12-24 | SMD Soldering - Hand Soldering - SOIC SSOP Packages (SOIC28, SSOP28)
SMD Soldering - Small Packages Androkavo 2017-12-16 | SMD Soldering - Hand Soldering - Small Packages : 0805, 0603, 0402, 0201, 01005Paste Flux Mechanic MCN-UV80 : goo.gl/zSSyHdBottle Dispenser : goo.gl/w7n3zAMicroscope Andonstar ADSM201 : goo.gl/8Ac9JhMusic : Carefree - Kevin MacLeod, Make it Shine - Sophonic, That Positive Feeling - Alumo
SMD Soldering - QFP100 Package Androkavo 2017-12-10 | SMD Soldering - Hand Soldering - QFP100 Package (0.5mm Pitch)
DIY Bluetooth Speaker Androkavo 2017-11-30 | DIY Bluetooth Speaker (5W + 5W) rechargeable with 18650 batteryMaterials : Bluetooth 4.0 CSR8645 : goo.gl/wXYioo2 Pin connector : goo.gl/2BnjNtTP4056 : goo.gl/oCESfCSpeaker 4 ohm 5W : goo.gl/bzbxjVSwitch On-Off : goo.gl/wqanUW18650 Battery Holder : goo.gl/xKUVFL18650 Battery : goo.gl/VkpNsJJute Twine Rope 20mm : goo.gl/Rp7eRuSchematic : goo.gl/s9uCB2
Simple Lamp With Hot Glue Gun Androkavo 2017-08-09 | Simple Lamp With Hot Glue GunMaterials : Paper 1mm thickness, Led 1W, 100 ohm resistor, Micro usb female connector, Glass mini bottle, Hot glue gun
ESP8266 Adapter Solderless Androkavo 2017-07-14 | ESP8266 v12 Adapter Solderless for update firmwareUse zigbee cc2530 adapter then swap pinsSchematic & pcb : drive.google.com/file/d/0B2IAuNuhuoM6WlZ6OWM4X2l2Tk0/view
Direct ink to PCB Androkavo 2017-06-20 | Direct ink to PCB with Flatbed Printer (Inkjet Printer)Best and easy way make PCB at hometest.eps : drive.google.com/file/d/0B2IAuNuhuoM6ZnV4N0JGOHF5dVE/viewFlatbed Printer (size A3) buy from printer shop in my location, approximate 2000$ (included tax), not sure price from elsewhere
DIY Wooden Digital Clock Androkavo 2017-05-14 | - DIY Wooden Digital Clock with WiFi controller- main components : STM8S005C6T6, ESP8266, DS1307, MAX7219, Led 7-Segment, DHT22 (Temp-Humi sensor), SW-420 (Vibration sensor), Buzzer, PLA box case, wood veneer stickerFeatures :- Time, Temperature, Humidity, Alarm- WiFi controller through web browser- Advance display config- Stop alarm by vibration sensorDownload project : http://www.instructables.com/id/Wooden-Digital-Clock- Idea & Concept 01:45- PCB Display 02:22..........design 03:19..........etching & solder mask 03:48..........parts 04:28..........solder 04:38- PCB Controller 06:27..........design 06:56..........parts 07:31..........programming 08:43..........design control page 09:22..........prepare upload firmware 10:02..........upload firmware 10:35..........solder 11:08- solder jack dc, switch, DHT22, buzzer 13:33- draw box case 14:29- 3d print 16:02- assembly 16:22- wood skin 18:08- complete & test 18:50
DIY Induction heater Androkavo 2017-03-24 | simple Induction heater 1000Wschematic : drive.google.com/file/d/0B2IAuNuhuoM6M0o3M3ZTWDh2LWc/view
DIY FlashLight Androkavo 2017-03-03 | 3D Print FlashLight, DIY FlashLight with microUSB chargerdownload 3D files : drive.google.com/file/d/0B2IAuNuhuoM6NGNWdmM3UU9ONTQ/view
How to make Custom Led Flashlight Androkavo 2016-12-05 | DIY Flashlight, DIY Led Flashlightdownload PCB files : drive.google.com/file/d/0B2IAuNuhuoM6d0VXR0YtaFRJbHc/view
How to make Street Lamp with paper Androkavo 2016-11-06 | DIY Street Lamp, Decorate Your HomeHow to make street lamp with paperdownload screenshot : drive.google.com/file/d/0B2IAuNuhuoM6MF94SHI5VVVtYzA/view
Solder wire test Androkavo 2016-10-29 | Solder wire test : #1 : PENGFA | 0:05 1:55#2 : ZHEN | 8:30#3 : MECHANIC | 14:16#4 : GUA | 17:10#5 : KUPING | 20:55#6 : ASAHI | 23:20#7 : LODESTAR | 25:36#8 : ASAHI (Lead free) | 27:41- LookAgain | 31:47- PinHeader | 42:18solder wire good with me : #3, #5, #6, #7, #8
