Uploaded May 2026 | Updated September 2026, 2 weeks ago
ACASIS TB504 ➡ geni.us/TB504 *Use code DAVID15 for 15% discount*
Testing RAID 0 performance on the ACASIS TB504 Thunderbolt 5 enclosure using four 4TB Samsung 9100 Pro NVMe SSDs in a 16TB APFS RAID 0 array with a 256K stripe size.
This video focuses on sustained real-world transfer performance using a 4TB mixed media workload, alongside synthetic benchmark testing against an 8TB dual-bus Thunderbolt 5 RAID built from two ACASIS TB501 Pro enclosures with WD Black SN850X SSDs. The video also shows what it takes to maintain high bandwidth throughput for SLC cache and TLC write speeds.
Key Results:
• 16TB TB504 RAID 0 Read Speed: ~6,921 MB/s
• 16TB TB504 RAID 0 Write Speed: ~6,680 MB/s
• Sustained 4TB write completed in 9m 46s
• Sustained TLC write speeds remained above 6 GB/s after SLC cache exhaustion
• Demonstration of aggregated SLC + TLC cache behaviour in a 4-drive RAID 0 setup
The testing also highlights the bandwidth differences between a single Thunderbolt 5 bus versus dual Thunderbolt 5 buses, and why large multi-drive RAID arrays can massively outperform single-drive setups in sustained professional workflows.
Hardware Used:
• ACASIS TB504 ➡ geni.us/TB504 *Use code DAVID15 for 15% discount*
• 4TB Samsung 9100 Pro 4TB SSDs 4TB amzn.to/4lpGMke
• ACASIS TB501 Pro TB501 Pro geni.us/TB501_Pro
• WD Black SN850X SSDs amzn.to/42RwzGr
• Apple MacBook Pro amzn.to/4uzK8q6
• AmorphousDiskMark bit.ly/4v6uoKS
More TB504 testing videos and enclosure links are in the description below.
Playlist for my TB504 FlowCore series videos: youtube.com/playlist?list=PLleKChtNUwZSvGWfRcsSZVwblC4m-Yu7A
Chapters:
00:00 Intro
00:54 Formatting the 16TB RAID 0
02:30 The 8TB RAID 0 source drive
03:22 Amorphous SSD speed test
05:35 Real world 4TB write speed test
10:07 Real world 4TB read speed test
12:50 Real world speed test results
14:01 End summary
