Female spider eating her partnerMahdi Esmaily2012-07-13 | That's what will happen if you don't do your job properly!
(From Life under growth - 2005)one sided separatorMahdi Esmaily2018-08-01 | When inertial particles that differ in size by 1% are placed in a precisely-constructed oscillatory shear flow, they exhibit drastically different behavior and segregate after a few oscillations.Time-evolution of a cloud of inertial particlesMahdi Esmaily2015-11-18 | A volumetric mesh, which represents a cloud of particles, is constructed based on a set of inertial particles. As particles move in a turbulent flow, the cloud deforms. This leads to contraction or expansion of cloud, providing an estimate for the divergence of particle velocity field.DNS of particle-laden turbulent duct flowMahdi Esmaily2015-11-17 | Direct numerical simulations of particle-laden flow in a duct. Reynolds is 10,000 and particles Stokes number is ~5.DNS of duct flowMahdi Esmaily2015-11-16 | Direct numerical simulation of turbulent flow in a square duct at Reynolds 20,000.Multiscale FSI simulationMahdi Esmaily2015-11-16 | Multiscale fully coupled fluid-structure interaction simulation of stage-one single ventricle surgical palliation.Stabilization formulation to prevent divergence caused by backflowMahdi Esmaily2015-11-16 | Simulation divergence, triggered by the backflow, is prevented non-intrusively by adding an extra stabilization term to the finite-element weak-formulation.Backflow with no treatmentMahdi Esmaily2015-11-16 | Neumann boundaries are vulnerable to backflow. This video demonstrates vortex shedding can trigger instabilities, causing a simulation to diverge.Particle laden flow DNSMahdi Esmaily2014-11-19 | DNS of particle laden flow in a straight channel exposed to radiation. On top particles are colored by temperature and on the bottom density contours are shown (red: high, blue: low).FSI simulation of single ventricle physiologyMahdi Esmaily2014-03-27 | This is stage one patient with a systemic-to-pulmonary shunt. The simulation is performed using fully closed-loop multiscale framework, in which inlet and outlets are all couple to lumped parameter network. Variable wall properties and thickness is used. ALE formulation with St.Venant Kirchhoff model is employed for the solid, allowing to capture large deformation.Simulation of pipe inflationMahdi Esmaily2014-03-05 | Fluid structure interation simulation of pipe filled by fluid. Two ends are clamped. Dirichlet boundary condition with constant flow is imposed at the inlet.FSI simulation of flow in a pipeMahdi Esmaily2014-02-20 | This is a ALE FSI simulation of the transition between stagnant flow to a steady flow in a straight pipe.Isogeometric analysis for fluid flow simulationMahdi Esmaily2014-02-12 | This model is generated using 7 patches. This is a 2D model of ABG, in which flow is injected from a high pressure inlet into a low pressure flow. Colors represent velocity magnitude.FSI simulation of a flexible beam in crossflowMahdi Esmaily2014-02-12 | Vortex shedding generates a fluctuation in pressure distribution on the beam and causes the beam to oscillate.CFD simulation of Assisted Bidirectional Glenn (ABG)Mahdi Esmaily2014-01-28 | ABG is a novel surgical concept, intended for palliation of single ventricle heart patients. In the ABG, the SVC is connected to the pulmonary artery and a extra connection is established between systemic circulation and the SVC via a shunt. This video shows high velocity shunt flow that is injected into the SVC.CFD simulation of bidirectional GlennMahdi Esmaily2014-01-28 | Simulation of Bidirectional Glenn surgery, using multiscale simulation. Colors represents velocity magnitude in a single cardiac cycle.Multiscale simulationMahdi Esmaily2014-01-27 | This is a multiscale simulation of circulation in a single ventricle patient. The flow at the inlet (ascending aorta) and the pressure at the outlets are calculated in a lumped parameter network (LPN) and passed to the 3D CFD domain.stabilized formulation to prevent backflow divergenceMahdi Esmaily2014-01-27 | Simulation divergence, triggered by the backflow, is prevented non-intrusively by adding an extra stabilization term to the formulation.Forcing velocity to be normal to the boundaryMahdi Esmaily2014-01-27 | While the regular formulation is unstable, forcing the velocity to be normal to the boundary is an intrusive method that changes the flow pattern of vortices that are advected through the outlet.No stabilization addedMahdi Esmaily2014-01-27 | Neumann boundaries are vulnerable to backflow. This video demonstrates vortex shedding can trigger simulation divergence, when regular formulation is employed.Mesh adaptation-2Mahdi Esmaily2013-03-29 | ...Mesh adaptationMahdi Esmaily2013-03-28 | Going from 20,000 tetrahedral elements to more than 4,000,000 elements in 5 stages of adaptation. The mesh is mostly refined in regions with high velocity and recirculation.
