In this video I practise wiring up the proximity sensors which I will use a limit switches on my CNC macihne. I will eventually have pairs for the X and Y axis wired in parallel and a single sensor for the Z. I plan to use two sensors on the X and Y axis so I can scan the margin and determine the available cutting distance between them. This may help me relocate bits white doing more complicated cutting jobs. That’s the idea anyway.
